Mechanical & Industrial Engineering (HVAC-R)
Central water-cooled chillers, multi-zone VRF systems, industrial cleanrooms, cyclone dust extraction, steam boiler loops, and food-grade stainless piping.
Executive Scope & Engineering Operations
Precision Engineering, Grounded in 19+ Years of Field Practice
Since our founding as Krysta Form Technical Products, our mechanical engineering division has engineered heavy HVAC-R, industrial ventilation, and process utility piping for food manufacturing plants, corporate towers, and commercial complexes across Nigeria. Our in-house plasma sheet metal duct manufacturing lines at Makogi ensure rapid deployment, zero air leakage, and exact compliance with international standards.
Verified Site Installation • Krysta Forms Operations
Systematic Scope of Work
Detailed Scope of Engineering Execution
Every system is engineered to international tolerances, backed by direct workshop staging and rigorous QA/QC documentation.
Central Chillers & VRF/VRV Air Conditioning
Turnkey cooling infrastructure engineered for West Africa's tropical climate and heavy thermal loads.
- Centrifugal and screw water-cooled & air-cooled industrial chiller plants (100TR – 800TR+).
- Variable Refrigerant Flow (VRF) inverter systems for corporate towers, banks, and luxury hotels.
- Precision computer room air handlers (CRAC) for data centers and server rooms.
- Building Management System (BMS) integration with automated temperature zoning and energy monitoring.
Industrial Ventilation & Cyclone Dust Extraction
Heavy manufacturing and food-grade factory environmental containment and air handling systems.
- High-volume cyclone dust collectors and particulate filtration systems (GB Foods Nigeria).
- Galvanized iron (GI) and 316-grade stainless steel kitchen and industrial exhaust hoods.
- Underground car park jet-fan ventilation and emergency smoke purge systems.
- Positive-pressure pharmaceutical cleanrooms and hospital operating theatres.
Piped Industrial Services & Steam Infrastructure
High-pressure process utility piping designed for continuous factory uptime and severe duty cycles.
- Steam boiler distribution loops, pressure reducing stations (PRV), and condensate return lines.
- Compressed air ring mains with refrigerated air dryers and pneumatic drop points.
- Chilled water insulated carbon steel and copper manifold systems with Armaflex cladding.
- Food and beverage sanitary stainless steel CIP (Clean-In-Place) piping (GB Foods).
Engineering Tolerances & Parameters
Technical Specifications & Design Criteria
The following table outlines the governing design codes, material standards, and performance specifications applied across this discipline.
| Engineering Parameter | Technical Specification & Range | Governing Standard / Quality Code |
|---|---|---|
| Central Chiller Cooling Capacity | Water-cooled centrifugal & air-cooled screw chillers (100TR – 800TR+) | COP ≥ 5.8 / AHRI Certified |
| VRF / VRV Inverter Systems | Multi-zone simultaneous cooling/heating inverter systems (8HP – 64HP) | Seasonal EER ≥ 4.2 |
| Custom Sheet Metal Ductwork | Galvanized iron (0.6mm–1.5mm) & stainless 316 spiral and rectangular | SMACNA Leakage Class 3 |
| Cyclone Dust Extraction | High-efficiency cyclone separators & reverse-pulse baghouse filtration | 99.5% particulate capture ≥ 5µm |
| Process Piping Pressure Rating | Food-grade 304/316 SS & Schedule 40/80 black steel carbon piping | Hydro-tested up to 30 Bar |
| Thermal & Acoustic Insulation | Closed-cell elastomeric Armaflex (9mm–32mm) & 50mm rockwool cladding | Class 0 Fire Rated (BS 476) |
Fabrication & Staging • Makogi Heavy Yard, Ogun State
Direct Machine Ownership
In-House Machinery & Calibrated Testing Rigs
We eliminate subcontracting bottlenecks by owning our core plasma cutting, hydro-testing, and electrical injection testing equipment across Lagos and Ogun State.
High-precision sheet metal HVAC duct profiling and geometric fittings
📍 Makogi Heavy Yard, Ogun State
Airtight duct seams, TDC/TDF flanged corners & low-leakage transitions
📍 Makogi Heavy Yard, Ogun State
Precise air volume balancing (CFM) & room air exchange rate verification
📍 Mobile HVAC Commissioning Squad
Deep system dehydration, nitrogen leak hold testing & R410a/R32 charging
📍 Mobile Mechanical Squad
Engineering Governance
5-Stage Project Delivery Lifecycle
Our structured 5-stage project methodology ensures zero discrepancy between architectural design, workshop fabrication, and on-site commissioning.
Cooling Load Calculation & Psychrometric Analysis
HAP/ASHRAE building cooling load calculations, fresh air CFM ventilation sizing, and CFD thermal modeling.
3D Ductwork & Piping Spatial Coordination
Detailed 3D layout of duct routing, chilled water risers, and clash elimination against electrical and structural elements.
Automated Plasma Sheet Metal Cutting & Flanging
CNC duct profiling, automated Pittsburg seam closing, acoustic internal lining, and factory QA seal checks.
Equipment Rigging, Nitrogen Brazing & Insulation Cladding
Chiller placement on vibration isolators, copper loop nitrogen brazing, steam line insulation, and duct hanging.
Testing, Adjusting & Balancing (TAB) & Handover
Air volume hood balancing, chilled water flow balancing, BMS integration, and operator training.
Quality Assurance & Handover
Certified Engineering Handover Deliverables
Every contract executed by Krysta Forms Limited concludes with an authoritative, audit-ready handover dossier including:
Proven Track Record
Representative Project Case Studies
Factory Air Conditioning & Cyclone Dust Extraction
Turnkey ventilation, heavy dust capture cyclones, and stainless food-processing ductwork.
Corporate Headquarters Complex HVAC Fitout
VRF central air conditioning, acoustic ducting, and fresh air intake systems.
Direct Engineering Consultation
Speak Directly with Our Technical Leads in Lagos & Ogun
Whether you have an upcoming tender, an architectural blueprint needing MEP coordination, or require heavy structural steel fabrication, our engineering directors are available for technical consultations.
